Rigol DS81304 13 GHz 4 Kanal 40GSa/s Dijital Osiloskop
DS80000 serisi dijital osiloskop, RIGOL tarafından bağımsız olarak geliştirilen sekizinci nesil dijital osiloskoptur. StationMAX II platformuna dayanan bu cihaz, 40GSa/s maksimum gerçek zamanlı örnekleme hızı ve 13GHz analog bant genişliğine ulaşır.
Rigol DS81304 13 GHz 4 Kanal 40GSa/s Dijital Osiloskop Teknik Özellikleri:
| Model | DS81304 |
| Bant Aralığı | 13 GHz |
| Kanal Sayısı | 4 |
| Real-Time Örnekleme Oranı | 40GSa/s |
| Max. Hafıza Derinliği | 4 Gpts (Opsiyonel) |
| Dalga Formu Yakalama Oranı | 250,000 wfms/s |
| Rise Time | ≤73 ps (6 GHz); ≤55 ps (8 GHz); ≤44 ps (10 GHz); ≤33 ps (13 GHz) (50 Ω impedance, 10%-90%, typ.) |
| Dikey Çözünürlük | 8-16 bit (Seçilebilir) |
| Ekran | 15.6'' multi-touch LCD Ekran |
| Boyutlar | 448 mm (G)×310 mm (Y)×522.6 mm (D) |
| Ağırlık | 28 Kg |
| Model | Bant Aralığı | Kanal Sayısı | Örnekleme Oranı | Max. Hafıza Derinliği | Dalga Formu Yakalama Oranı |
| DS80604 | 6 GHz | 4 | 40 GSa/s | 4 Gpts | 250,000 wfms/s |
| DS80804 | 8 GHz | 4 | 40 GSa/s | 4 Gpts | 250,000 wfms/s |
| DS81004 | 10 GHz | 4 | 40 GSa/s | 4 Gpts | 250,000 wfms/s |
| DS81304 | 13 GHz | 4 | 40 GSa/s | 4 Gpts | 250,000 wfms/s |
Based on the StationMAX II hardware technology platform, it achieves a maximum real-time sampling rate of 40GSa/s and an analog bandwidth of 13GHz, which can more realistically restore signals and cover more applications.
Based on the RIGOL new generation UltraVision III platform, it achieves a maximum storage depth of 4Gpts, allowing DS80000 to have high-fidelity signal acquisition capability and capture waveforms for longer periods of time at high sampling rates.
The DS80000 series adopts the RIGOL SmartProbe 2.0 interface, supports direct signal connection with 3.5mm connectors, and is equipped with RIGOL's self-developed probe adapter. It can also be backward compatible with the previous generation of RIGOL original probes, providing convenience for your use.
DS80000 has a maximum analog bandwidth of 13GHz and a maximum real-time sampling rate of 40GSa/s, which can meet the performance verification of high-speed devices and systems, high-speed bus compliance analysis, DDR debugging and other application scenarios, helping engineers solve more testing challenges
